The Biodeconta Glove Integrity Tester GISTOOL-50, boasting professional performance and high adaptability, has emerged as the preferred equipment for glove testing in domestic aseptic production environments, safeguarding the safety of aseptic production.

In terms of usage flexibility, the device incorporates a high-performance battery and an air pump, eliminating reliance on external power sources and air supplies. It can operate independently in any location, such as aseptic workshops and laboratories, completely breaking free from usage scenario constraints and meeting the mobile testing needs across multiple regions.

When it comes to data management and device control, its advantages are equally notable:

• Convenient Data Output: Equipped with a USB interface, detection data can be exported to printing devices at any time without the need for additional adapter tools, ensuring timely storage and traceability of detection results.
• Flexible Control Modes: Supports two modes—independent single-device operation and multi-device group control. It can be expanded as required based on production scales and detection needs, suitable for both small-batch single-point detection and large-scale centralized detection management.
• Efficient Networking Capability: Featuring an RFID identification function, a single system can meet the networking requirements of over 200 devices, enabling multi-device data synchronization and real-time status monitoring, significantly enhancing detection efficiency.
•


Additionally, the device offers a flange size customization service, accurately matching the installation scenarios of sterile gloves of different specifications and fully catering to customers’ personalized needs.

As an entry-level leak tester, the GISTOOL-50, while ensuring professional-level detection accuracy and stable performance, enjoys the price advantage of being economical and affordable. It allows enterprises to make investments with high cost-effectiveness and gain a reliable aseptic protection detection experience.

Functional Advantages

• Simple yet Sophisticated: Equipped with a USB interface, detection data can be printed at any time, ensuring convenience and efficiency.
• High-Performance Detection: Leveraging the core NTC-Lite testing component, it can accurately detect 300μm apertures in regular mode.
• RFID Intelligent Identification: Automatically identifies device connections, supporting the networking of over 200 devices to meet large-scale detection needs.
•


Customization & Expansion

• Custom Collar: Collar dimensions support customization to adapt to diverse requirements.
• Single-Unit / Group-Control Dual Modes: Supports independent operation of a single unit or flexible expansion to group-control mode, fitting different management scenarios.
• Optional Accessories: Differential pressure sensor metering accessories can be selected as needed to expand functions.
•


Performance & Design

• Stable and Excellent: Equipped with a high-precision differential pressure sensor (accuracy 0.2%), ensuring reliable and accurate detection data.
• Integrated Design: Built-in air pump, with the whole machine ingeniously integrated, independently completing the entire process of inflation testing.
• High-Performance Battery: Equipped with a long-life battery to ensure stable operation of the device for an extended period.
•


Product Specifications

• Dimensions: 280×230×75cm | Weight: 3.0kg (excluding the glove sealing collar), lightweight and portable for easy deployment.

Main Unit Accessories (Fully Equipped)

• Equipment main unit
• Custom collar (quick-release patent)
• Server, tablet, router
• Charger, aviation case, user manual, small trolley
•


Matching Gloves (Customizable to Meet Requirements)

• Partner manufacturers: Covering mainstream brands such as PIERCAN, NORTH (HONEYWELL), RotAdler, etc.
• Material and size: CSM (Hypalon) and nitrile materials are available; multiple specifications from 7 inches to 12 inches are covered.
• Shape adaptation: Round and oval collar types are available, with front-mounting and reverse-mounting assembly methods, flexibly matching scenarios.
•


The operation is extremely simple, with no need for additional software installation. The function configuration, from detection precision to deployment flexibility, comprehensively meets the needs of scenarios such as aseptic production, providing a professional and efficient solution for glove integrity detection.

Core Positioning

Focus on aseptic isolation devices, providing professional solutions for glove integrity testing and safeguarding the aseptic production line.

Functional Highlights

• Full-process Management: Covers multi-level permission management, audit trails, visual testing, electronic signatures, and user hierarchical management. It enables full-lifecycle control of gloves, supports custom test parameters and customized glove collars, and flexibly adapts to diverse needs.
• Compliance and Standards: Developed in accordance with GB/T25915.7 - 2010 and ISO 14644 - 7:2004 standards, complying with regulations such as FDA/GMP and computer system validation requirements. The software meets 21CFR part11 electronic record and electronic signature certifications, follows the repeatable and verifiable test procedures of ISO 14644 - 7, and supports IQO and PQ verification to ensure compliant and reliable detection.
•


Technical Advantages

• Wireless Group Control Design: Breaks through the limitations of device coordination, supports the simultaneous operation of more than 200 devices. Equipped with functions such as anti-false signatures, rapid testing, audit trails, and recipe definition, it efficiently coordinates the detection processes of multiple devices and facilitates test management in large-scale aseptic scenarios.
